Carbon Fiber Packing Rope Wear Resistant Packing Gland Packing for Valve Customizable (20×20mm)

Length: 1meter
 Specification:
 Name: Carbon Fiber diameter: 6 mm*6 mm,8mm*8 mm,10mm*10 mm,12 mm*12 mm,14 mm*14 mm,16 mm*16 mm,18 mm*18 mm,20mm*20mm, ★Can be customized into gaskets, rings

 Please contact me for other sizes
 Performance characteristics: Carbonized fiber coil, also known as pre - oxygen wire coil, is made of acrylic fiber pre - oxidized woven coil, surface using ptfe emulsion and lubrication treatment. Carbonized fiber coil has excellent thermal conductivity, wear resistance and chemical stability, and is relatively inexpensive in non-asbestos products. It is the ideal asbestos substitute. According to customer requirements can be molded into carbonized fiber packing ring. Equipment: Sealing of valves, pumps, flanges, agitators, mixers, stern shafts, etc. Industry: Petroleum, metallurgy, chemical, fertilizer, power generation, instrumentation and other industrial equipment. Medium: The application field is quite wide. Such as: weak acid, alkali, salt, organic solvent, seawater, factory waste water, mineral oil and other media. Product specifications: 3*3mm- 70*70mm; Special specifications or all kinds of non-standard products can be made according to customer requirements Carbonized fiber coil main technical parameters: Temperature -50-260(℃) Rotary pump 2.5mpa, Reciprocating pump 15 mpa, The valve 15 mpa Ph (Ph range) 1-13 The Linear speed is 15m/s

• * ★Great Heat Insulation,Abration Resistant, Chemical Resistant
• * ★ Firm, High Density,No Aging No Shrinkage
• * ★Excellent for water pump seal
• *★Can be customized into gaskets, rings
• *★Impregnated with PTFE emulsion for lubrication
